Features

• Bore range: up to 80mm
• Nom. Transmitting Torque: 3924Nm
• Designed for press-fit installation into the housing via the outer race
• The housing internal diameter must be machined to an H7 tolerance
• Installation with a Type 63 bearing is required to avoid radial loading, as the clutch does not include integrated bearing support
• Keyways are required on the end faces of the clutch for secure installation, however they are not necessary if the housing internal diameter is machined to K6 tolerance
• The housing must have sufficient strength to withstand the forces generated during press-fit installation
• Oil lubrication is required for operation
